Anti-corrosion & Anti-bump Steel Electric Diesel Generator for Backup Power Supply
· High-Capacity Output
· Easy to Transport & Deploy
· Long-Lasting Durability
· Anti-Corrosion & Anti-Bump Design
· Heavy-Duty Steel Structure
· Reliable Backup Power Supply
· Durable & Long-Lasting
· Withstand Harsh Environments
- Overview
- Specification
- Partnership
- Company
- FAQ
- Recommended Products
Yuchai Marine Electric 5KW Diesel Generator is specially developed for marine working conditions, equipped with original Yuchai marine single-cylinder power. It has a prime power of 5KW, maximum power of 5.5KW and rated speed of 3000r/min, complying with relevant marine standards, featuring anti-bump, anti-corrosion and low fuel consumption, suitable for small ship emergency and regular power supply.
With a special marine structure design, the unit is compact and lightweight, with a reference size of 700×500×660mm and a weight of about 105KG, suitable for the limited installation space of ships. Matched with a marine brushless generator, it adopts AVR automatic voltage regulation for stable voltage, with protection class IP23, suitable for the humid and salty marine environment.
Adopting manual/electric dual-start mode, it is easy to operate and has multiple protections such as overload, low oil pressure and over-temperature. The fuel consumption is as low as 0.7-0.9L/hour, with a 16L fuel tank for reliable endurance. Relying on Yuchai Marine Electric's exclusive after-sales service, it features convenient operation and maintenance, strong accessory adaptability and high cost performance.
Main Technical Parameters of YC5GF-D - Unit Parameters
| Yuchai Model | YC5GF-D |
| Rated Frequency | 50Hz |
| Rated Rotational Speed | 3000r/min |
| Rated Voltage | 230V |
| Rated Power | 5kW |
| Maximum Power | 5.5kW |
| Number of Phases | Single-phase |
| Excitation Method | Brushed Self-excitation Constant Voltage (with AVR) |
| Type | Open Frame Standard |
| Fuel Tank Capacity | 18L |
| Comprehensive Running Time | 10h |
| Noise | <103dB(A)@7m |
| Weight | 108kg |
| Dimensions (L×W×H) | 726×522×685mm |
| With Wheels | Handle + Two 9-inch Fixed Direction Wheels |
Main Technical Parameters of YC5GF-D - Power Parameters
| Power Model | CP188FE |
| Starting Method | Manual/Electric Start |
| Power Type | Single-cylinder, Four-stroke, Air-cooled, Diesel Engine |
| Cylinder Bore × Piston Stroke | 88×75mm |
| Displacement | 456cc |
| Compression Ratio | 19:1 |
| Rated Power | 6.5kW/3000r/min |
| Oil Filling Capacity | 1.65L |
| Fuel Type | 0# Diesel (Summer), -10# Diesel (Winter), -35# Diesel (Extreme Cold) |
| Lubricating Oil Type | SAE10W30 (Above Grade CD) |
